Fusion SM-F65CW Shallow Mount Speakers 6.5in 100W White

Unique shallow mount design without compromising on sound
quality

The new Fusion SM-F65CW Shallow Mount Speakers are
designed for installations where mounting depth is limited without
compromising on sound quality and performance. The SM Series
speakers are engineered with a sealed, perfectly-tuned enclosure to
deliver quality audio reproduction that normally could not be
achieved from the limitations of shallow mounting depths. These
speakers are a stylish addition to your vessel with its clean
aesthetics and unique shallow mount form factor.

Quality audio reproduction with unique shallow mount
design
The SM Series speakers solves the age-old problem of achieving
quality audio reproduction from the limitations of shallow mounting
depths often required in many installations. By engineering a
tuned, sealed enclosure into the back of the speaker, it eliminates
the need to have sufficient volume behind the speaker for quality
audio reproduction.

This makes the SM Series speakers capable of producing high-quality
sound even with one of the most restrictive mounting depths of only
24mm (15/16″), allowing them to be installed in areas many other
speakers will not fit, such as cabinets.

IP65 Weatherproof
The SM Series speakers are designed for the harsh marine
environment and are rated IP65 for water and dust ingress
protection from the front when installed correctly, while also
meeting industry standards for UV and salt fog protection.

Fusion SM-F65CW Shallow Mount Speakers
Features:

• Shallow Basket Design: with a shallow mounting depth of only
  24mm, the SM Series speakers are ideal for installation where
  mounting depth is limited
• Tuned, Sealed Enclosure Design: protects the speakers’
  components from damage and ensures quality audio reproduction is
  delivered that normally could not be achieved by a speaker with
  such a shallow design
• Retrofittable: the SM Series speakers have a circular back with
  a mounting diameter clearance of 130mm, allowing it to fit easily
  into existing 6.5″ speaker cutouts.
• Aesthetic Interior Design: designed with aesthetics in mind,
  the SM Series come with a high-end acoustic fabric grille and
  feature rounded edges and contour cues to add style to your
  vessel
• IP65 Weatherproof: the SM Series speakers are rated IP65 for
  protection against dust and water ingress in the harsh marine
  environment

Fusion SM-F65CW Shallow Mount Speakers
Specifications:

• Speaker Enclosure Size: 155mm x 155mm [6-1/8″ x
  6-1/8″]
• Peak Power Rating: 100 Watts
• Driver Size: Tuned and optimised 3″
• Efficiency (1W/1M): 84 dB
• Frequency Response: 150 Hz – 20 kHz
• Nominal Impedance: 4 Ohms
• Cone / Surround Material: Polypropylene with rubber
  surround
• Mounting Diameter Clearance: 130mm [5-1/8″]
• Mounting Depth Clearance: 24mm [15/16″]
• Operating Temperature Range: 0 to 50°C (32 to 122°F)
• Storage Temperature Range: -20 to 70°C (-4 to 158°F)
• Water and Dust Resistance (IPX rating): IP65
• Warranty: 1 year
• Colour: White

Note: This speaker comes with a fabric grille,
and it’s recommended for indoor installations only. If you plan to
install the speaker outdoors, you should purchase a plastic grille
instead.
